text box: metallized polypropylene epoxy case, rectangular axial lead capacitors

text box: ne metallized polypropylene epoxy case, rectangular axial lead regular series























DIMENSIONS See tables for specific T, W, L values

                                                                     WIRE SIZE (Length 1.50 in. minimum)



BODY LENGTH (L)

WIRE SIZE

AWG No.

Diameter

  ≤ .65 “

24

.020”

  > .65” ≤ 1.06”

22

.025”

  > 1.06”

20

.032”





ORDERING DESCRIPTION

Capacitor, Fixed: Metallized Polypropylene dielectric, extended foil construction, tin-plated copper clad steel wire axial leads,

encased in a flame retardant epoxy / plastic shell with epoxy fill.

APPLICATION NOTES

Epoxy case capacitors are not intended for exposure to high humidity conditions over extended periods of time.

For stringent environmental conditions, Epoxy Case capacitors should be used in encapsulated or hermetically sealed circuitry.



  All designs utilize materials that meet or exceed UL flammability requirements per UL94VO.



SELECTION AND ORDERING TABLE Select voltage rating, capacitance and tolerance, read Part Number to the right.

MFD

100VDC   80VAC

200VDC   120VAC

400VDC   320VAC

RATING

T

W

L

PART #

T

W

L

PART #

T

W

L

PART #



+.01”

+.01”

±..03”



+.01”

+.01”

±.03”



+.01”

+.01”

±.03”



.0010

.0015

.0022

.0033

.0047



.0068

.0082

.010

.015

.022



.033

.047

.068

.082

.10



.15

.22

.33

.47

.68



.82

1.0

2.0

4.7

5.0













.17

.17

.17

.17

17



.17

.17

.17

.17

.17



.17

.17

.17

.17

.23



.23

.29

.29

.29

.39



.39

.39

.56

.56

.56













.29

.29

.29

.29

.29



.29

.29

.29

.29

.29



.29

.29

.29

.29

.36



.36

.42

.42

.42

.54



.54

.54

.72

.72

.72













.42

.42

.42

.42

.42



.42

.42

.42

.42

.42



.55

.55

.55

.55

.55



.55

.55

.67

.82

.82



.82

1.24

1.24

1.75

1.75













NE1-102E

NE1-152E

NE1-222E

NE1-332E

NE1-472E



NE1-682E

NE1-822E

NE1-103E

NE1-153E

NE1-223E



NE1-333E

NE1-473E

NE1-683E

NE1-823E

NE1-104E



NE1-154E

NE1-224E

NE1-334E

NE1-474E

NE1-684E



NE1-824E

NE1-105E

NE1-205E

NE1-475E

NE1-505E













.17

.17

.17

.17

17



.17

.17

.17

.17

.17



.17

.23

.23

.29

.29



.29

.29

.39

.39

.39



.39

.56

.56

















.29

.29

.29

.29

.29



.29

.29

.29

.29

.29



.29

.36

.36

.42

.42



.42

.42

.54

.54

.54



.54

.72

.72

















.42

.42

.42

.42

.42



.42

.42

.42

.55

.55



.55

.55

.55

.55

.55



.67

.82

.82

1.04

1.24



1.24

1.24

1.75

















NE2-102E

NE2-152E

NE2-222E

NE2-332E

NE2-472E



NE2-682E

NE2-822E

NE2-103E

NE2-153E

NE2-223E



NE2-333E

NE2-473E

NE2-683E

NE2-823E

NE2-104E



NE2-154E

NE2-224E

NE2-334E

NE2-474E

NE2-684E



NE2-824E

NE2-105E

NE2-205E

















.17

.17

.17

.17

17



.17

.17

.17

.23

.23



.29

.29

.29

.29

.39



.39

.39

.39

.56

.56



.56

.56



















.29

.29

.29

.29

.29



.29

.29

.29

.36

.36



.42

.42

.42

.42

.54



.54

.54

.54

.72

.72



.72

.72



















.42

.42

.42

.42

.42



.42

.55

.55

.55

.55



.55

.67

.67

.82

.82



.82

1.04

1.24

1.24

1.24



1.75

1.75



















NE4-102E

NE4-152E

NE4-222E

NE4-332E

NE4-472E



NE4-682E

NE4-822E

NE4-103E

NE4-153E

NE4-223E



NE4-333E

NE4-473E

NE4-683E

NE4-823E

NE4-104E



NE4-154E

NE4-224E

NE4-334E

NE4-474E

NE4-684E



NE4-824E

NE4-105E





















text box: tolerance a = ± 1%●, b = ± 2%●, c = ± 3%●, d = ± 5%, e = ± 10%, none = ± 20% table ● temperature stabilized









Note: Replace the last digit E with the desired tolerance code from the Tolerance Table below. For in-between capacitance values,

use the next larger value’s dimensions. Please consult factory for additional voltage ratings and special or custom requirements.







Electron Products Inc. ◊ 5367 Third Street, Irwindale, CA 91706 ◊ Phone 626-960-2299 ◊ Fax 626-814-4434

Web Site http://www.ElectronProductsInc.Com ◊ E-Mail Sales@ElectronProductsInc.Com
