DIMENSIONS See tables
for specific T, H, L values
WIRE
SIZE (Length 1.50 in. minimum)
** Mounting pads
consist of two individual pads
BODY LENGTH (L) |
LEAD SPACING(C) C to C ± .01 |
WIRE
SIZE
|
|
AWG No. |
Diameter
|
||
.42 |
.300 |
22 |
.025 |
.55 |
.400 |
22 |
.025 |
.67 |
.500 |
22 |
.025 |
.82 |
.600 |
22 |
.025 |
1.04 |
.800 |
22 |
.025 |
1.24 |
1.100 |
20 |
.032 |
1.75 |
1.60 |
20 |
.032 |
on each end or one
continuous pad on each end,
depending on the mold.
(Not an option)
ORDERING
DESCRIPTION
Capacitor,
Fixed: Metallized Polypropylene dielectric, extended foil construction,
tin-plated copper clad steel wire axial leads,
encased
in a flame retardant epoxy / plastic shell with epoxy fill.
APPLICATION
NOTES
Epoxy
case capacitors are not intended for exposure to high humidity conditions over
extended periods of time.
For
stringent environmental conditions, Epoxy Case capacitors should be used in
encapsulated or hermetically sealed circuitry.
All designs utilize materials that meet or exceed UL
flammability requirements per UL94VO.
SELECTION
AND ORDERING TABLE Select voltage rating, capacitance and
tolerance, read Part Number to the right.
MFD |
100VDC
80VAC |
200VDC
120VAC |
400VDC
230VAC |
|||||||||
RATING |
T |
H |
L |
PART # |
T |
H |
L |
PART # |
T |
H |
L |
PART # |
|
+.01 |
+.01 |
±..03 |
|
+.01 |
+.01 |
±.03 |
|
+.01 |
+.01 |
±.03 |
|
.0010 .0015 .0022 .0033 .0047 .0068 .0082 .010 .015 .022 .033 .047 .068 .082 .10 .15 .22 .33 .47 .68 .82 1.0 2.0 4.7 5.0 |
.18 .18 .18 .18 .18 .18 .18 .18 .18 .18 .18 .18 .18 .18 .24 .24 .30 .30 .30 .40 .40 .40 .57 .57 .57 |
.30 .30 .30 .30 .30 .30 .30 .30 .30 .30 .30 .30 .30 .30 .37 .37 .43 .43 .43 .55 .55 .55 ..73 .73 .73 |
.42 .42 .42 .42 .42 .42 .42 .42 .42 .42 .55 .55 .55 .55 .55 .55 .55 .67 .82 .82 .82 1.24 1.24 1.75 1.75 |
N2E1-102E N2E1-152E N2E1-222E N2E1-332E N2E1-472E N2E1-682E N2E1-822E N2E1-103E N2E1-153E N2E1-223E N2E1-333E N2E1-473E N2E1-683E N2E1-823E N2E1-104E N2E1-154E N2E1-224E N2E1-334E N2E1-474E N2E1-684E N2E1-824E N2E1-105E N2E1-205E N2E1-475E N2E1-505E |
.18 .18 .18 .18 .18 .18 .18 .18 .18 .18 .18 .24 .24 .30 .30 .30 .30 .40 .40 .40 .40 .57 .57 |
.30 .30 .30 .30 .30 .30 .30 .30 .30 .30 .30 .37 .37 .43 .43 .43 .43 .55 .55 .55 .55 .73 .73 |
.42 .42 .42 .42 .42 .42 .42 .42 .55 .55 .55 .55 .55 .55 .55 .67 .82 .82 1.04 1.24 1.24 1.24 1.75 |
N2E2-102E N2E2-152E N2E2-222E N2E2-332E N2E2-472E N2E2-682E N2E2-822E N2E2-103E N2E2-153E N2E2-223E N2E2-333E N2E2-473E N2E2-683E N2E2-823E N2E2-104E N2E2-154E N2E2-224E N2E2-334E N2E2-474E N2E2-684E N2E2-824E N2E2-105E N2E2-205E |
.18 .18 .18 .18 .18 .18 .18 .18 .24 .24 .30 .30 .30 .30 .40 .40 .40 .40 .57 .57 .57 .57 .70 |
.30 .30 .30 .30 .30 .30 .30 .30 .37 .37 .43 .43 .43 .43 .55 .55 .55 .55 .73 .73 .73 .73 1.13 |
.42 .42 .42 .42 .42 .42 .55 .55 .55 .55 .55 .67 .67 .82 .82 .82 1.04 1.24 1.24 1.24 1.75 1.75 1.75 |
N2E4-102E N2E4-152E N2E4-222E N2E4-332E N2E4-472E N2E4-682E N2E4-822E N2E4-103E N2E4-153E N2E4-223E N2E4-333E N2E4-473E N2E4-683E N2E4-823E N2E4-104E N2E4-154E N2E4-224E N2E4-334E N2E4-474E N2E4-684E N2E4-824E N2E4-105E N2E4-205E |
Note:
Replace the last digit E with the desired tolerance code from the Tolerance
Table below. For in-between capacitance values,
use
the next larger values dimensions. Please consult factory for additional
voltage ratings and special or custom requirements.
